Overview

Asterope’s Digital Audio Multi-Pair Suite is built for the uncompromising professional — offering a fully scalable family of balanced digital audio cable assemblies optimized for low-noise, high-reliability signal transmission. Precision-built in the U.S.A. to exceed AES/EBU 110Ω standards, these cables are engineered to perform under the demanding requirements of studios, live production, fixed installations, and broadcast environments. This suite includes multiple conductor gauges and pair configurations to accommodate any scale of deployment — from patch panels and OB trucks to high-channel-count rack systems and campus-wide A/V backbones.

Key Features (All Models)

• AES/EBU 110Ω Impedance Compliance
  Built to exceed industry standard for digital audio signal transmission, ensuring clean waveform delivery and accurate clock data.

• Shielded and Bonded Foil Design
  Full-coverage foil shields for each individual pair with optional overall braided shield — ensuring consistent crosstalk rejection and minimal EMI interference.

• Low Capacitance, High Flexibility
  Engineered for optimal audio performance with uniform dielectric spacing and precision twist ratios, preserving waveform shape across long distances.

• Numbered, Color-Coded Pairs
  Clear and durable labeling system for fast field identification and error-free installations.

• Made in the U.S.A.
  All assemblies are handcrafted and terminated in the U.S. using Asterope's proprietary manufacturing protocols for exceptional precision and reliability.

Product Variants & Applications

1. Standard AES/EBU Multi-Pair Assemblies (110Ω, General Purpose)

• Conductor Gauge: 22 AWG (Standard)

• Pair Counts: 2, 4, 8, 12, 16, 24

• Use Case: General-purpose installations, mobile rigs, patchbays, fixed system interconnects

2. High-Density 22 AWG Assemblies (Extended Distance)

• Conductor Gauge: 22 AWG

• Shielding: Bonded foil + optional braid

• Use Case: Long-distance transmission, infrastructure-grade backbone, low-loss digital audio distribution

3. Expanded Range Configurations

• Pair Counts: 2 to 48

• Design Flexibility: Available with customizable shielding options, outer jackets, and termination styles

• Use Case: Enterprise or institutional-scale A/V networks, production studios, large-scale audio system integration

Specifications Snapshot (Typical Values)

Parameter: Specification Range
Impedance: 110Ω ± 10%
Conductor Type: Stranded Tinned Copper (22AWG)
Shielding: Foil per pair + optional overall braid
Jacket Material: Flexible PVC or LSZH
Pair Identification: Numbered / Color-coded
Capacitance: < 40 pF/ft (typical)
Operating Temp Range: -20°C to +60°C
Compliance: RoHS / REACH
Assembly Location: USA

Available Formats

• Multipair Cable Assemblies: 2–48 pair

• Termination Options: DB25, XLR, EDAC, Phoenix, custom

• Delivery Formats: Standard lengths or custom cut-to-length drums

Why Asterope?

Precision-engineered with Asterope’s proprietary design language, these multipair digital audio solutions represent a commitment to purity, durability, and professional-grade system integrity. Whether routed through a concert rig or installed across a broadcast facility, Asterope cables ensure your digital audio arrives uncorrupted — every time.

Disclaimer: Specifications reflect typical performance ranges based on in-house testing and standard applications. For custom configurations or extended-environment deployments, consult Asterope for performance validation and installation guidelines. All products built and tested in compliance with applicable AES/EBU and IEC standards.

Overview

Asterope’s Tactical Cat5E Assemblies are purpose-built for harsh deployment environments where durability, signal fidelity, and physical resilience are mission-critical. These ruggedized assemblies offer high mechanical strength, excellent EMI shielding, and outstanding signal integrity under stress — making them ideal for field broadcast, aerospace support, military comms, and mobile infrastructure.

Key Features (All Models)

• Double-Jacketed Construction
  Abrasion-resistant polyurethane outer jacket with an inner LSZH (Low Smoke Zero Halogen) core for fire safety and compliance.

• Enhanced Shielding
  Individually foil-shielded pairs and an overall braided shield (FTP) for superior protection against crosstalk and EMI.

• High-Strand Count Conductors
  Flexible stranded copper conductors optimized for repeated handling without signal degradation.

• Field-Rated Connectors
  Available with IP67-rated or mil-spec RJ45 connectors. All connectors feature reinforced boots, strain relief, and options for color-coding or locking mechanisms.

• High-Flex Durability
  Designed for 5,000+ flex cycles — ideal for repeated deployment, coiling, and retraction in demanding environments.

• Performance Rated to 350 MHz
  Exceeds ANSI/TIA-568-C.2 and ISO/IEC 11801 performance requirements for Cat5E. Optimized conductor geometry and proprietary bonding reduce signal loss and return loss across longer distances.

Product Applications

Live outside broadcast (OB) rigs and camera feeds

• Tactical military comms and mobile command networks

• Emergency response and disaster recovery deployments

• Touring AV and live-event network backbones

• Temporary aerospace and UAV test deployments

Specifications Snapshot (Typical Values)

Conductor Type: Stranded Bare Copper (24 AWG typical)
Shielding: FTP (Foil Twisted Pair + Braid)
Jacket Material: Polyurethane (outer) / LSZH (inner)
Flex Life: 5,000+ Cycles
Bandwidth: Up to 350 MHz
Connector Options: Hardened RJ45, IP67, Mil-Spec
Operating Temp Range: -40°C to +75°C (typical)
RoHS / REACH Compliance: Yes
Assembly Location: USA (Hand-Assembled)

Available Formats

• Pre-Terminated Assemblies: 10 ft – 250 ft

• Custom Lengths: Made to order

• Drum Packaging: Available for bulk orders or field kits

Why Asterope?

While most Ethernet cabling is built for static, indoor applications, Asterope’s Tactical Cat5E is engineered for motion, friction, flex, and failure resistance. Every assembly is handcrafted in the United States to ensure exacting tolerances, exceptional build quality, and consistent field-ready performance.

Disclaimer: Performance specifications are based on internal testing and/or benchmarking against published industry norms. Actual field results may vary depending on installation conditions, connector selection, and network configuration. For mission-critical use, contact Asterope for recommended deployment practices and testing protocols.

Overview

Asterope’s Industrial Control & Power Cables are engineered for performance in ruggedized, high-demand environments — delivering reliable power and signal control for automation, robotics, and mission-critical industrial systems. Built with high-strand-count bare copper conductors, optimized shielding, and durable jacketing, these assemblies support distributed power infrastructure while maintaining electrical stability in noise-heavy industrial zones. Available in multiple configurations and jacket options, these cables offer the flexibility and resilience required for both stationary and mobile machinery.

Key Features (All Models)

• High-Strand-Count Copper Conductors
  Enhanced flexibility and conductivity using finely stranded bare copper (12 or 13 AWG), ideal for installations requiring tight turns or repetitive movement.

• Overall Aluminum Shielding (O/A Foil)
  Protects against electromagnetic interference (EMI) and signal distortion, especially when routed alongside motors, sensors, or high-voltage systems.

• Voltage and Current Handling
  Supports moderate-to-high current delivery for distributed industrial control panels, actuators, and power bus systems.

• Robust Outer Jacket
  Industrial-grade thermoplastic or thermoset jacketing options available, providing abrasion, oil, and chemical resistance in factory environments.

• UL/CSA & RoHS Compliance
  All assemblies designed to meet applicable North American and international safety standards.

Product Applications

• PLC and machine control cabling

• Distributed power bus systems

• Factory automation and smart systems

• Robotics, conveyor, and assembly line wiring

• Sensor-actuator network infrastructure

• Test & measurement environments

Specifications Snapshot (Typical Values)

Conductor Size: 12 AWG or 13 AWG Bare Copper
Stranding: High-strand-count (flex-rated)
Shielding: Overall Aluminum Foil (O/A)
Voltage Rating: 600V (standard industrial grade)
Jacket Options: PVC / TPE / LSZH (based on environment)
Temperature Rating: -30°C to +90°C (varies by jacket)
Flexibility Rating: Moderate to High (flex-rated design)
Compliance: UL, CSA, RoHS
Assembly Origin: USA

Available Formats

• Conductor Count: 2C, 3C, 4C, 5C, 7C (custom on request)

• Pre-Terminated or Raw Assemblies: Available cut-to-length or with custom termination

• Jacket Colors: Black (standard), gray, yellow, or custom-coded

Why Asterope?

Asterope’s industrial assemblies are designed for integrators, manufacturers, and engineers who demand reliability under pressure. Whether installed in a robotics cell, factory floor, or automated distribution system, our control and power cables provide clean, consistent delivery of energy and signal. Precision, consistency, and rugged durability — all handcrafted in the USA.

Disclaimer: Product performance values are representative and based on in-house evaluation and typical field deployment. For critical infrastructure applications or environments with special compliance requirements, consult with Asterope engineering for material validation, customization, or compliance documentation.

Overview

Asterope’s DMX and Lighting Control Cables are engineered for absolute data fidelity in digitally controlled lighting and automation systems. Designed around the 120Ω RS-485 transmission standard, these precision cables feature twisted pair conductors with dual shielding to ensure exacting timing, zero signal reflection, and minimal packet loss — critical in dynamic lighting environments where synchronization is paramount. Whether in a live stage rig, architectural install, or intelligent control grid, Asterope DMX cables deliver clean and consistent performance.

Key Features (All Models)

• RS-485 Protocol Compliance (120Ω Nominal)
  Maintains impedance consistency and tight electrical tolerances for accurate digital communication in DMX, RDM, and other lighting control protocols.

• Foil + Braid Shielding
  Combines 100% foil coverage with an additional tinned copper braid for outstanding protection against RF and EMI — essential for densely populated lighting environments.

• Low Capacitance & Tight Pair Twist
  Reduces signal delay and maintains data clarity across long DMX runs — especially important for venues and productions with multiple lighting universes.

• Rugged & Flexible Jacket Options
  Available in touring-grade polyurethane or flame-retardant PVC, depending on install or mobile needs.

• Connector-Ready Construction
  Termination-ready for 3-pin and 5-pin XLR, Phoenix, or proprietary DMX control connectors. Suitable for field or factory assembly.

Product Applications

• Stage lighting and theater automation

• Concert and touring rigs

• Intelligent architectural lighting systems

• Digital signage and control systems

• Audio-visual integration and LED displays

Specifications Snapshot (Typical Values)

Impedance: 120Ω ± 10%
Conductor Type: Stranded Tinned Copper (22–24 AWG)
Shielding: Foil + Tinned Copper Braid
Jacket Material: PVC / PU / LSZH (based on environment)
Capacitance: < 40 pF/ft (typical)
Voltage Rating: 300V (typical control voltage)
Temperature Range: -20°C to +80°C
Flame Rating: UL VW-1 / FT1 (depends on jacket)
Compliance: RS-485, DMX512-A, RoHS
Assembly Origin: USA

Available Formats

• Conductor Pairing: Single Pair (2C) or Dual Pair (4C)

• Shielding Options: Foil only or Foil + Braid

• Termination: Available pre-terminated or raw

• Color Options: Black (standard), Blue (DMX), or custom-coded jackets

Why Asterope?

Lighting data doesn’t just require bandwidth — it requires precision. Asterope’s DMX and lighting control cables are purpose-engineered to deliver timing accuracy, low noise, and long-run stability. Whether in a world-class stage venue or a tightly packed festival rig, our RS-485-compliant cables keep the lights moving in perfect sync.

Disclaimer: Product specifications represent standard build configurations and typical application scenarios. For high-interference installations, permanent architectural installs, or compliance-specific venues, consult Asterope for custom builds, fire ratings, and system-specific cable matching.

Overview

Asterope’s Fiber Optic Cable Solutions are engineered for the new era of ultra-high-speed data delivery, supporting mission-critical operations across broadcast, aerospace, defense, and enterprise-grade communication networks. Designed for flawless transmission of digital signals over extreme distances with virtually no loss, our single-mode and multimode assemblies offer the perfect fusion of bandwidth, durability, and precision. With meticulous core alignment, premium polish quality, and ruggedized construction, Asterope fiber solutions ensure signal integrity in applications where speed, reliability, and electromagnetic immunity are non-negotiable.

Key Features (All Models)

• Single-Mode and Multimode Options
  Supports both long-distance single-mode (OS1/OS2) and high-throughput multimode (OM2/OM3/OM4) applications. Available in simplex, duplex, and breakout configurations.

• High Bandwidth & Low Latency
  Delivers up to 100 Gbps per channel with minimal signal degradation. Ideal for environments requiring real-time control, massive data flows, or latency-sensitive synchronization.

• Ruggedized Jacket Construction
  Jackets available in tactical-rated polyurethane, tight-buffer PVC, or plenum-rated LSZH. Crush-resistant and flexible for mobile and fixed installations.

• Precision Polish and Connectorization
  LC, SC, ST, and MTP/MPO factory-terminated ends with high-quality APC/UPC polish options ensure low insertion loss and optimal return loss characteristics.

• Immunity to EMI/RFI
  Unlike copper-based systems, fiber is 100% immune to electromagnetic interference, ensuring stable performance near power sources, transmitters, or switching gear.

• Field-Tested for Harsh Environments
  Available with armored jackets, water-blocking gel layers, and UV-resistant sheathings for outdoor or tactical deployments.

Product Applications

• Studio-to-control room digital backbone

• Aerospace and avionics communication links

• Defense tactical field networks

• Campus-wide enterprise LAN/WAN systems

• Broadcast and OB truck high-bandwidth feeds

• Remote sensor and instrumentation uplinks

• Live-event video transport and switching grids

Specifications Snapshot (Typical Values)

Parameter Single-Mode (OS2)

Core Diameter: 9 µm
Wavelength Support: 1310 / 1550 nm
Bandwidth: >10 Gbps to 100 Gbps
Insertion Loss: (Typical) < 0.35 dB
Return Loss: > 55 dB (APC)
Jacket Ratings: PVC, LSZH, Tactical PU
Crush Resistance: Up to 2200 N/100 mm
Temperature Range: -40°C to +75°C
Compliance: TIA-568, ISO/IEC 11801
Assembly Origin: USA

Parameter Multimode (OM3/OM4)

Core Diameter: 50 µm / 62.5 µm
Wavelength Support: 850 / 1300 nm
Bandwidth: Up to 100 Gbps (short range)
Insertion Loss: (Typical) < 0.3 dB
Return Loss: > 35 dB (UPC)
Jacket Ratings: PVC, LSZH, Tactical PU
Crush Resistance: Up to 2200 N/100 mm
Temperature Range: -40°C to +75°C
Compliance: TIA-568, ISO/IEC 11801
Assembly Origin: USA

Available Formats

• Core Types: OS2, OM1, OM2, OM3, OM4

• Connector Types: LC, SC, ST, FC, MTP/MPO

• Cable Styles: Simplex, Duplex, Fanout, Breakout, Armored

• Jacket Options: Indoor/Outdoor, Riser, Plenum, Tactical

• Pre-Terminated Lengths: 3 ft to 1,000+ ft, custom available

Why Asterope?

In today’s data-driven environments, performance bottlenecks are no longer tolerable. Asterope Fiber Optic Cable Solutions are designed for speed without sacrifice — offering unmatched precision, polish, and protection. From live-event broadcasting to military field applications, our fiber builds stand resilient, fast, and true. With full assembly and testing performed in the USA, each cable is guaranteed to meet exacting tolerances and deliver on what matters most: speed, signal clarity, and uptime reliability.

Disclaimer: Product specifications are representative of standard configurations and performance profiles. Custom polishing, termination, or jacket configurations may alter certain electrical or physical properties. Please contact Asterope for environmental-specific builds, insertion loss certification, or passive/active integration support.
