Overview

Asterope’s Digital Audio Multi-Pair Suite is built for the uncompromising professional — offering a fully scalable family of balanced digital audio cable assemblies optimized for low-noise, high-reliability signal transmission. Precision-built in the U.S.A. to exceed AES/EBU 110Ω standards, these cables are engineered to perform under the demanding requirements of studios, live production, fixed installations, and broadcast environments. This suite includes multiple conductor gauges and pair configurations to accommodate any scale of deployment — from patch panels and OB trucks to high-channel-count rack systems and campus-wide A/V backbones.

Key Features (All Models)

• AES/EBU 110Ω Impedance Compliance
  Built to exceed industry standard for digital audio signal transmission, ensuring clean waveform delivery and accurate clock data.

• Shielded and Bonded Foil Design
  Full-coverage foil shields for each individual pair with optional overall braided shield — ensuring consistent crosstalk rejection and minimal EMI interference.

• Low Capacitance, High Flexibility
  Engineered for optimal audio performance with uniform dielectric spacing and precision twist ratios, preserving waveform shape across long distances.

• Numbered, Color-Coded Pairs
  Clear and durable labeling system for fast field identification and error-free installations.

• Made in the U.S.A.
  All assemblies are handcrafted and terminated in the U.S. using Asterope's proprietary manufacturing protocols for exceptional precision and reliability.

Product Variants & Applications

1. Standard AES/EBU Multi-Pair Assemblies (110Ω, General Purpose)

• Conductor Gauge: 22 AWG (Standard)

• Pair Counts: 2, 4, 8, 12, 16, 24

• Use Case: General-purpose installations, mobile rigs, patchbays, fixed system interconnects

2. High-Density 22 AWG Assemblies (Extended Distance)

• Conductor Gauge: 22 AWG

• Shielding: Bonded foil + optional braid

• Use Case: Long-distance transmission, infrastructure-grade backbone, low-loss digital audio distribution

3. Expanded Range Configurations

• Pair Counts: 2 to 48

• Design Flexibility: Available with customizable shielding options, outer jackets, and termination styles

• Use Case: Enterprise or institutional-scale A/V networks, production studios, large-scale audio system integration

Specifications Snapshot (Typical Values)

Parameter: Specification Range
Impedance: 110Ω ± 10%
Conductor Type: Stranded Tinned Copper (22AWG)
Shielding: Foil per pair + optional overall braid
Jacket Material: Flexible PVC or LSZH
Pair Identification: Numbered / Color-coded
Capacitance: < 40 pF/ft (typical)
Operating Temp Range: -20°C to +60°C
Compliance: RoHS / REACH
Assembly Location: USA

Available Formats

• Multipair Cable Assemblies: 2–48 pair

• Termination Options: DB25, XLR, EDAC, Phoenix, custom

• Delivery Formats: Standard lengths or custom cut-to-length drums

Why Asterope?

Precision-engineered with Asterope’s proprietary design language, these multipair digital audio solutions represent a commitment to purity, durability, and professional-grade system integrity. Whether routed through a concert rig or installed across a broadcast facility, Asterope cables ensure your digital audio arrives uncorrupted — every time.

Disclaimer: Specifications reflect typical performance ranges based on in-house testing and standard applications. For custom configurations or extended-environment deployments, consult Asterope for performance validation and installation guidelines. All products built and tested in compliance with applicable AES/EBU and IEC standards.
